| Place of Origin: | China |
|---|---|
| Brand Name: | HUAguard |
| Certification: | ROHS/CE/FCC |
| Model Number: | HUA-101S |
| Minimum Order Quantity: | 1 |
| Price: | USD 45/pc |
| Packaging Details: | 1 set/box,10 boxes/small carton,30 boxes/big carton |
| Delivery Time: | 3-5 work days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 500 pcs/day |
| Material: | PVC | Weight: | 170g |
|---|---|---|---|
| Color: | Black | Read Mode: | RFID |
| Frequency: | 125khz | Dimension: | 158*32*30mm |
| High Light: | tracking Guard Patrol Monitoring System,Guard Patrol Monitoring System 0.12MAh,Monitoring security guard wand system |
||
Durable PVC Texture 0.12 mAh Standby Current Low Power Consumption Security Patrol Guard Tour Stick
Durable Standby Low Power Consumption Security Patrol Guard Tour Stick
1. Description
Security patrol guard tour stick HUA-101S, which is made of durable PVC texture, has 0.12mAh standby current and low power consumption. Storage capacity: 60,000 data stores, which can be customized expanded to 120,000 data stores. Communication mode: USB communication mode, no need to install USB driver, plug and play. The support operating system of the software is XP/Win7 / Win8(32/64 bit), support Access, Sql server database. English and other languages can be customized. Communication is micro USB compatible connection. When the device reads the card or checkpoints, it will have triple prompt: audio, LED lighting, vibration. Lighting function: flashlight lighting function. Operating temperature and operating humidity are -40℃~ 70℃ and 0-95% respectively.
2. Charcteristics
HUA-101S electronic security patrol device has e600 LED lighting. The device's flashlight LED is made of CREE XM-L2, imported from the United States. It has a life of more than 30,000 hours, which is the longest life of LED lights on the market. Its card reading type is RFID with 125khz frequency. HUA-101S patrol device's battery power consumption is that standby current is within 0.12 mA, and power consumption is 0.45 mW. Battery capacity: 650 mA polymerized physical battery, battery life: 14 days The diameter of the device's the card reading head coil is 38mm, and the coil is large. Card reading distance: non-contact induction, 3-5 cm.
3. Parameters
| Dimension | 158*32*30 mm | ||||
| Weight | 170g | ||||
| Read mode | RFID 125khz | ||||
| Read distance | 3-5 cm | ||||
| Read indication | Light and beep, light and vibration(optional) | ||||
| Memory capacity | 16MB, can store 60,000 piece records | ||||
| Battery | 3.6V 650mah rechargeable lithium battery | ||||
| Battery life | A full charge can support about 30days, 200 times reading per day | ||||
| Communication | USB cable to transmit data to computer | ||||
| Software | Stand-alone, multi-language, free | ||||
| Working temperature | -20℃-70℃ | ||||
4. Usage
(1) Used for patrolling
(2) Widely used in Communities, Hospitals, School, Construction site, Industries, etc.
5. What will be included in per set?
One set includes:
*4 charing plugs for you to choose, please connect us and select as needed.*
| Length | Width | Height | |
| Single package size | 22cm | 17cm | 6cm |
| 10pcs package size | 37cm | 35cm | 25cm |
| 30pcs package size | 53cm | 35cm | 46cm |
6. Delivery
The goods will be delivered within 3-5 working days with UPS, DHL, FedEx after receiving the payment.
7. FAQ
Q1: Are you a factory or a trade company?
Reply :We are a factory located in Shenzhen, China, welcome to visit our factory at any time.
Q2: How many days can I get the products if I placed purchase order?
Reply : In general, about 1-3 working days for Sample and ready stock; 15 working days for production order after receving order deposit.
Q3: Which payment can be accepted?
Reply: T/T, Paypal, Western Union and L/C etc.
Q4: When did you start?
Reply : We have started our factory from year 2000, and we have experience of producing and developing Biometric attendance and access control terminals for more than 15 years. All of our engineers are professors in this area.
